Product Name:Angle Grinder
Model
S1M-TM02-100
Rated Voltage(V~)
220v
Rated Frequency(Hz)
50Hz
Max.Wheel Diameter(mm)
Φ100
Hole Diameter of Wheel(mm)
Φ16
Rated Power Input(W)
670
Rated Speed(r/min)
11000
Net.Weight (kg)
1.9
Order No
A2
Mill-cut quickly
Performance characteristics

1    partno:311210025    Wheel Guard    12    partno:323710023    Clamp Nut    13    partno:323810026    Disc Flange    14    partno:320210061    Output Shaft    15    partno:234110008    Screw M4*12    46    partno:310410001    Metal Dust Protector    17    partno:530310135    Gear Case Cover    18    partno:250110156    Bearing 6201-2RS    19    partno:240710005    Circlip for Hole 32    110    partno:320110078    Gear    111    partno:250210023    Needle Bearing HK0810    112    partno:320710009    Lock Pin    113    partno:234110019    Screw ST4*24    414    partno:340510022    Spring for lock pin 8.8*13*0.7*5    115    partno:522410006    Pin Cap    116    partno:532410114    Gear Case    117    partno:221410008    Nut M6    118    partno:320110125    Bevel Pinion    119    partno:250110010    Bearing 608-2RS    120    partno:141610005    Seal Ring 25*22*4    121    partno:240710004    Circlip for hole 27    122    partno:524810002    Blinker    123    partno:510210372    Armature    124    partno:521610024    Insulation ring    125    partno:250110157    Bearing 607-2RS    126    partno:140810006    Bearing Seat    127    partno:520310020    Winding-proof Ring    128    partno:510110142    Stator    129    partno:520110443    Housing    130    partno:430210038    Brush holder    131    partno:234610002    Tapping Screw ST3*10    132    partno:430110021    Carbon Brush    133    partno:340420015    Coil Spring 2.6*0.3*5    134    partno:450210009    Terminal    235    partno:440210002    Capacity 0.33uF-2TH    136    partno:522710041    Rear Housing    137    partno:234110028    Screw ST4*20    138    partno:522310012    Switch Button    139    partno:410110051    Switch    140    partno:310610003    Strain Relief (stamped)     141    partno:234110033    Screw ST3*10    142    partno:522210002    Rod    143    partno:621911819    Nameplate    144    partno:340110002    Rod Spring 5*25*0.5*12    245    partno:450210002    Terminal    146    partno:140310001    Power Cable Jacket    147    partno:420110093    Power Cable 2*0.75*2.7YZW    1
